MEP System Structure in Hierarchical JSON Graph

Originally Published in

The Building Coder

Yesterday, I presented the new TraverseAllSystems ↗ add-in to traverse all MEP system graphs and export their connected hierarchical structure to JSON and XML that I am helping the USC ↗ team with here at the San Francisco cloud accelerator.

San Francisco cloud accelerator

I continued with that today, and also integrated a minor enhancement to RevitLookup:

TraverseAllSystems Updates

The aim of the TraverseAllSystems project is to present the MEP system graphs in a separate tree view panel integrated in the Forge viewer ↗ and hook up the tree view nodes bi-directionally with the 2D and 3D viewer elements.

To achieve that, I implemented a couple of significant enhancements over the simple XML file storage:

  • Store the MEP system graph structure in JSON instead of XML
  • Implement both bottom-up and top-down storage according to the jsTree JSON spec ↗.
  • Support both element id and UniqueId node identifiers.
  • Store the JSON output in a shared parameter attached to the MEP system element, so that it is automatically included in the Forge SVF translation generated from the RVT input file.

Here is a list of the update releases so far:

  • 2017.0.0.2 ↗ – implemented visited element dictionary to prevent infinite recursion loop
  • 2017.0.0.3 ↗ – implemented DumpToJson
  • 2017.0.0.4 ↗ – implemented shared parameter creation
  • 2017.0.0.5 ↗ – implemented shared parameter value population, tested and verified graph structure json is written out
  • 2017.0.0.6 ↗ – renamed json text field to name
  • 2017.0.0.7 ↗ – implemented top-down json graph storage
  • 2017.0.0.8 ↗ – automatically create shared parameter, eliminated separate command, wrap json strings in double quotes, validated json output

Shared Parameter Creation

I implemented a new SharedParameterMgr class to create the shared parameter to store the JSON output in.

This class is based on the ExportCncFab ↗ ExportParameters.cs module ↗.

The shared parameter is automatically created if not already present, as in the following usage example:

// Check for shared parameter
// to store graph information.

Definition def = SharedParameterMgr.GetDefinition(
  desirableSystems.First<MEPSystem>() );

if( null == def )
{
  SharedParameterMgr.Create( doc );

  def = SharedParameterMgr.GetDefinition(
    desirableSystems.First<MEPSystem>() );

  if( null == def )
  {
    message = "Error creating the "
      + "storage shared parameter.";

    return Result.Failed;
  }
}

Here is the SharedParameterMgr class implementation:

/// <summary>
/// Shared parameters to keep store MEP system
/// graph structure in JSON strings.
/// </summary>
class SharedParameterMgr
{
  /// <summary>
  /// Define the user visible shared parameter name.
  /// </summary>
  const string _shared_param_name = "MepSystemGraphJson";

  /// <summary>
  /// Return the parameter definition from
  /// the given element and parameter name.
  /// </summary>
  public static Definition GetDefinition( Element e )
  {
    IList<Parameter> ps = e.GetParameters(
      _shared_param_name );

    int n = ps.Count;

    Debug.Assert( 1 >= n,
      "expected maximum one shared parameters "
      + "named " + _shared_param_name );

    Definition d = ( 0 == n )
      ? null
      : ps[0].Definition;

    return d;
  }

  /// <summary>
  /// Create a new shared parameter definition
  /// in the specified grpup.
  /// </summary>
  static Definition CreateNewDefinition(
    DefinitionGroup group,
    string parameter_name,
    ParameterType parameter_type )
  {
    return group.Definitions.Create(
      new ExternalDefinitionCreationOptions(
        parameter_name, parameter_type ) );
  }

  /// <summary>
  /// Create the shared parameter.
  /// </summary>
  public static void Create( Document doc )
  {
    /// <summary>
    /// Shared parameters filename; used only in case
    /// none is set and we need to create the export
    /// history shared parameters.
    /// </summary>
    const string _shared_parameters_filename
      = "shared_parameters.txt";

    const string _definition_group_name
      = "TraverseAllSystems";

    Application app = doc.Application;

    // Retrieve shared parameter file name

    string sharedParamsFileName
      = app.SharedParametersFilename;

    if( null == sharedParamsFileName
      || 0 == sharedParamsFileName.Length )
    {
      string path = Path.GetTempPath();

      path = Path.Combine( path,
        _shared_parameters_filename );

      StreamWriter stream;
      stream = new StreamWriter( path );
      stream.Close();

      app.SharedParametersFilename = path;

      sharedParamsFileName
        = app.SharedParametersFilename;
    }

    // Retrieve shared parameter file object

    DefinitionFile f
      = app.OpenSharedParameterFile();

    using( Transaction t = new Transaction( doc ) )
    {
      t.Start( "Create TraverseAllSystems "
        + "Shared Parameters" );

      // Create the category set for binding

      CategorySet catSet = app.Create.NewCategorySet();

      Category cat = doc.Settings.Categories.get_Item(
        BuiltInCategory.OST_DuctSystem );

      catSet.Insert( cat );

      cat = doc.Settings.Categories.get_Item(
        BuiltInCategory.OST_PipingSystem );

      catSet.Insert( cat );

      Binding binding = app.Create.NewInstanceBinding(
        catSet );

      // Retrieve or create shared parameter group

      DefinitionGroup group
        = f.Groups.get_Item( _definition_group_name )
        ?? f.Groups.Create( _definition_group_name );

      // Retrieve or create the three parameters;
      // we could check if they are already bound,
      // but it looks like Insert will just ignore
      // them in that case.

      Definition definition
        = group.Definitions.get_Item( _shared_param_name )
          ?? CreateNewDefinition( group,
            _shared_param_name, ParameterType.Text );

      doc.ParameterBindings.Insert( definition, binding,
        BuiltInParameterGroup.PG_GENERAL );

      t.Commit();
    }
  }
}

Options

I implemented a new Options class to control two settings:

  • Use element id or UniqueId for to identify node
  • Store JSON graph bottom-up or top-down

The class implementation is short, sweet and trivial:

class Options
{
  /// <summary>
  /// Store element id or UniqueId in JSON output?
  /// </summary>
  public static bool StoreUniqueId = false;
  public static bool StoreElementId = !StoreUniqueId;

  /// <summary>
  /// Store parent node id in child, or recursive
  /// tree of children in parent?
  /// </summary>
  public static bool StoreJsonGraphBottomUp = false;
  public static bool StoreJsonGraphTopDown
    = !StoreJsonGraphBottomUp;
}

The two bottom-up and top-down JSON storage structures both comply with the jsTree JSON spec ↗.

Bottom-Up JSON Structure

[
  { "id" : "ajson1", "parent" : "#", "text" : "Simple root node" },
  { "id" : "ajson2", "parent" : "#", "text" : "Root node 2" },
  { "id" : "ajson3", "parent" : "ajson2", "text" : "Child 1" },
  { "id" : "ajson4", "parent" : "ajson2", "text" : "Child 2" },
]

Top-Down JSON Structure

{
  id: -1,
  name: 'Root',
  children: [
  {
    id: 0,
    name: 'Mechanical System',
    children: [
    {
      id: 0_1,
      name: 'Child 0_1',
      type: 'window',
      otherField: 'something...',
      children: [
      {
        id: 0_1_1,
        name: 'Grandchild 0_1_1'
      }]
    }, {
      id: 0_2,
      name: 'Child 0_2',
      children: [
      {
        id: 0_2_1,
        name: 'Grandchild 0_2_1'
      }]
    }]
  }, {
    id: 2,
    name: 'Electrical System',
    children: [
    {
      id: 2_1,
      name: 'Child 2_1',
      children: [{
        id: 2_1_1,
        name: 'Grandchild 2_1_1'
      }]
    },
    {
      id: 2_2,
      name: 'Child 2_2',
      children: [{
        id: 2_2_1,
        name: 'Grandchild 2_2_1'
      }]
    }]
  },
  {
    id: 3,
    name: 'Piping System',
    children: [
    {
      id: 3_1,
      name: 'Child 3_1',
      children: [{
        id: 3_1_1,
        name: 'Grandchild 3_1_1'
      }]
    },
    {
      id: 3_2,
      name: 'Child 3_2',
      children: [{
        id: 3_2_1,
        name: 'Grandchild 3_2_1'
      }]
    }]
  }]
}

TraversalTree JSON Output Generator

The two TraversalTree JSON output generators DumpToJsonTopDown and DumpToJsonBottomUp are pretty trivial as well, since all the work is done by the individual tree nodes:

/// <summary>
/// Dump the top-down traversal graph into JSON.
/// In this case, each parent node is populated
/// with a full hierarchical graph of all its
/// children, cf. https://www.jstree.com/docs/json.
/// </summary>
public string DumpToJsonTopDown()
{
  return m_startingElementNode
    .DumpToJsonTopDown();
}

/// <summary>
/// Dump the bottom-up traversal graph into JSON.
/// In this case, each child node is equipped with
/// a 'parent' pointer, cf.
/// https://www.jstree.com/docs/json/
/// </summary>
public string DumpToJsonBottomUp()
{
  List<string> a = new List<string>();
  m_startingElementNode.DumpToJsonBottomUp( a, "#" );
  return "[" + string.Join( ",", a ) + "]";
}

TreeNode JSON Output Generator

The two TreeNode JSON output generators are only slightly more complicated.

Here are the two formatting strings that they use:

/// <summary>
/// Format a tree node to JSON storing parent id
/// in child node for bottom-up structure.
/// </summary>
const string _json_format_to_store_parent_in_child
  = "{{"
  + "\"id\" : {0}, "
  + "\"name\" : \"{1}\", "
  + "\"parent\" : {2}}}";

/// <summary>
/// Format a tree node to JSON storing a
/// hierarchical tree of children ids in parent
/// for top-down structure.
/// </summary>
const string _json_format_to_store_children_in_parent
  = "{{"
  + "\"id\" : {0}, "
  + "\"name\" : \"{1}\", "
  + "\"children\" : [{2}]}}";

Here are the two recursive functions implementing the JSON output:

static string GetName( Element e )
{
  return e.Name.Replace( "\"", "'" );
}

static string GetId( Element e )
{
  return Options.StoreUniqueId
    ? "\"" + e.UniqueId + "\""
    : e.Id.IntegerValue.ToString();
}

/// <summary>
/// Add JSON strings representing all children
/// of this node to the given collection.
/// </summary>
public void DumpToJsonBottomUp(
  List<string> json_collector,
  string parent_id )
{
  Element e = GetElementById( m_Id );
  string id = GetId( e );

  string json = string.Format(
    _json_format_to_store_parent_in_child,
    id, GetName( e ), parent_id );

  json_collector.Add( json );

  foreach( TreeNode node in m_childNodes )
  {
    node.DumpToJsonBottomUp( json_collector, id );
  }
}

/// <summary>
/// Return a JSON string representing this node and
/// including the recursive hierarchical graph of
/// all its all children.
/// </summary>
public string DumpToJsonTopDown()
{
  Element e = GetElementById( m_Id );

  List<string> json_collector = new List<string>();

  foreach( TreeNode child in m_childNodes )
  {
    json_collector.Add( child.DumpToJsonTopDown() );
  }

  string json_kids = string.Join( ",", json_collector );

  string json = string.Format(
    _json_format_to_store_children_in_parent,
    GetId( e ), GetName( e ), json_kids );

  return json;
}

Download and To Do

The current state of this project is available from the TraverseAllSystems GitHub repository ↗, and the version discussed above is release 2017.0.0.9 ↗.

The next step will consist of the Forge viewer extension implementation displaying a custom panel in the user interface hosting a tree view of the MEP system graphs and implementing two-way linking and selection functionality back and forth between the tree view nodes and the 2D and 3D viewer elements.

RevitLookup Updates

A couple of enhancement have been added to RevitLookup ↗ since I last mentioned it, most lately by awmcc90 ↗ and Shayne Hamel ↗ to handle exceptions snooping MEP elements, electrical circuits, flex ducts and flex pipes.

Here are the diffs:

  • 2017.0.0.5 ↗ – merged pull request #14 by Shayneham to handle exceptions snooping flex pipe and duct lacking levels etc.
  • 2017.0.0.4 ↗ – merged pull request #13 by awmcc90 to skip mepSys.Elements for OST_ElectricalInternalCircuits category

Thank you very much for those improvements!

If you run into any issues with RevitLookup yourself, please fork the repository, implement and test your changes, and issue a pull request for me to integrate them back into the master branch.

Thank you!
